2024 KTM 200 DUKE
2024 KTM 200 DUKE
*Advertised 'Ride Away Price' including dealer fees, set-up and (if applicable) 12 months registration.
separator
Inquiring for 2024 KTM 200 DUKE
Fill out the form below and one of our friendly sales team will be in touch.
LIGHT HEAVYWEIGHT
It rides faster than it looks. This fighter is the only 200cc naked bike with real racing genes. High-tech components – such as the ultra-compact, water-cooled, single-cylinder, 4-stroke engine, dual-channel ABS and the ultralight tubular trellis frame, state-of-the-art injection electronics, cutting-edge WP suspension and elegant swingarm – are all perfectly integrated to ensure maximum riding fun and dynamic cornering.
MODEL
YEAR
TECHNICAL SPECIFICATION
| Drive typeCombustion |
| Torque19.5 Nm |
| Transmission6-speed |
| CoolingLiquid cooled |
| Power in KW19 kW |
| StarterElectric starter |
| Stroke49 mm |
| Bore72 mm |
| ClutchWet multi-disc clutch, mechanically actuated |
| Compression ratio11.5 |
| Displacement199.5 cm³ |
| EMSBosch EMS |
| Engine oilMotorex Formula 4T |
| Design1-cylinder, 4-stroke engine |
| Fuel-mixture generationBosch EFI (throttle valve 38 mm) |
| LubricationWet sump |
| Tank capacity (approx.)13.5 l |
| ABSBosch 9.1MB Two Channel ABS |
| Front brake disc diameter300 mm |
| Rear brake disc diameter230 mm |
| Front brakeFour-piston radial fixed calliper, brake disc |
| Rear brakeSingle-piston floating calliper, brake disc |
| ChainX-Ring 5/8 x 1/4" |
| dry weight140 kg |
| Frame designSteel trellis frame, powder coated |
| Front suspensionWP-USD, AER 43, Ø 43 mm |
| HandlebarAluminium, tapered Ø 26/22 mm |
| Rear suspensionWP monoshock |
| Seat height823 mm |
| SilencerStainless steel primary and aluminium secondary silencer |
| Steering head angle65 ° |
| Rear subframe designSteel trellis frame, powder coated |
| Suspension travel (front)142 mm |
| Suspension travel (rear)161 mm |
| Wheelbase1367 mm |
| Ground Clearance155 mm |
| WheelsCast aluminium wheels |
| Wheelbase Tolerance15 mm |
| Front wheel diameter17 " |
| Rear wheel diameter17 " |
| Front wheel width3 " |
| Rear wheel width4 " |
