2024 KTM 250 EXC
2024 KTM 250 EXC
*Advertised 'Ride Away Price' including dealer fees, set-up and (if applicable) 12 months registration.
separator
RACE TO NEW HEIGHTS
The 2024 KTM 250 EXC presents enduro riders with the ultimate combination of power and rideability, setting the benchmark in the highly contested E1 class. Thanks to its groundbreaking new frame, suspension, and TBI technology, this extreme machine continues to reach new heights. How far you push, thought, it is up to you.
MODEL
YEAR
TECHNICAL SPECIFICATION
| Transmission6-speed |
| Clutch primary drive teeth72 |
| StarterElectric starter |
| Stroke72 mm |
| Bore66.4 mm |
| ClutchWet, DDS multi-disc clutch, Brembo hydraulics |
| Displacement249 cm³ |
| EMSVitesco Technologies EMS |
| Design1-cylinder, 2-stroke engine |
| Fuel-mixture generationKeihin EFI, throttle body 39 mm |
| Tank capacity (approx.)9 l |
| Front brake disc diameter260 mm |
| Rear brake disc diameter220 mm |
| Front brakeDisc brake |
| Rear brakeDisc brake |
| Chain520 X-Ring |
| Frame designCentral double-cradle-type 25CrMo4 steel |
| Front suspensionWP XACT-USD, Ø 48 mm |
| HandlebarNeken, aluminium Ø 28/22 mm |
| Rear suspensionWP Xplor PDS shock absorber |
| SilencerAluminium |
| Steering head angle63.9 ° |
| Rear subframe designAluminum-reinforced polyamide |
| Weight (without fuel)104.9 kg |
| Seat height963 mm |
| Wheelbase1489 mm |
| Ground clearance347 mm |
| Suspension travel (front)300 mm |
| Suspension travel (rear)310 mm |
| WheelsSpoked wheels with aluminium rims |
