2024 KTM 250 SX-F
2024 KTM 250 SX-F
*Advertised 'Ride Away Price' including dealer fees, set-up and (if applicable) 12 months registration.
separator
THE MOST RADICAL 250-CLASS RACE WEAPON
The 2024 KTM 250 SX-F continues its assault on the highly-competitive 250 cc class. Featuring a truly user-friendly package engineered to satisfy all riders, from novice to pro, it continues the trend of being undisputedly READY TO RACE at any level. Delivering a knock-out power-punch of over 47 hp, more stability in a straight line, and with more electronic upper cuts in the bag, the 2024 KTM 250 SX-F is ready to take on the 250 cc class and dominate it.
MODEL
YEAR
TECHNICAL SPECIFICATION
| Transmission5-speed |
| Clutch primary drive teeth72 |
| StarterElectric starter |
| Stroke48.5 mm |
| Bore81 mm |
| ClutchWet multi-disc DS clutch, Brembo hydraulics |
| Compression ratio14.5 |
| Displacement249.9 cm³ |
| EMSKeihin EMS |
| Design1-cylinder, 4-stroke engine |
| Fuel-mixture generationKeihin EFI, throttle body 44 mm |
| Tank capacity (approx.)7.2 l |
| Front brake disc diameter260 mm |
| Rear brake disc diameter220 mm |
| Front brakeDisc brake |
| Rear brakeDisc brake |
| Chain520, Non-sealed |
| Frame designCentral double-cradle-type 25CrMo4 steel |
| Front suspensionWP XACT-USD, Ø 48 mm |
| HandlebarNeken, aluminium Ø 28/22 mm |
| Rear suspensionWP XACT Monoshock with linkage |
| SilencerAluminium |
| Steering head angle63.9 ° |
| Rear subframe designAluminum-reinforced polyamide |
| Wheelbase1493 mm |
| Ground Clearance359 mm |
| Seat height958 mm |
| Suspension travel (front)310 mm |
| Suspension travel (rear)300 mm |
| WheelsSpoked wheels with aluminium rims |
