2024 KTM 390 ADVENTURE
2024 KTM 390 ADVENTURE
*Advertised 'Ride Away Price' including dealer fees, set-up and (if applicable) 12 months registration.
MAKE LIFE A DARING ADVENTURE
Merging all-road versatility and proven reliability with real-world performance, The 2024 KTM 390 ADVENTURE makes heading on an adventure an everyday possibility. Powered by a proven 373 cc powerplant churning out 44 HP via a 6-speed gearbox, a class-leading chassis, and a 400 km tank range thanks to a 14.5-litre tank, it hits the road with purposeful intent. Whats more, adjustable 43 mm WP APEX forks, 170 mm of wheel travel, OFFROAD MODE, and the option of 19/17" heavy-duty tubed spoked wheels, mean it is perfectly suited to the trail too. Download the full technical data sheet at the bottom for more info.
This motorcycle is designed and developed in Austria, and assembled in India.
TECHNICAL SPECIFICATION
| Drive Type Combustion |
| Torque 37 Nm |
| Transmission6-speed |
| CoolingLiquid cooled |
| StarterElectric starter |
| Stroke60 mm |
| Bore89 mm |
| ClutchPASC™ antihopping clutch, mechanically operated |
| CO2 emissions78 g/km |
| Compression ratio12.6 |
| Displacement373.2 cm³ |
| EMSBosch EMS with RBW |
| Engine oilMotorex Formula 4T 15W/50 |
| Design1-cylinder, 4-stroke engine |
| Fuel consumption3.37 l/100 km |
| Fuel-Mixture GenerationBosch EFI (throttle valve 46 mm) |
| LubricationWet sump |
| Tank Capacity (Approx.)14.5 l |
| ABSBosch 9.1 MP (incl. Cornering-ABS and offroad mode, disengageable) |
| Front Brake Disc Diameter320 mm |
| Rear Brake Disc Diameter230 mm |
| Front Brake Four-piston radial fixed calliper |
| Rear Brake Single-piston floating calliper, brake disc |
| Chain520 X-Ring |
| Dry Weight161 kg |
| Frame DesignSteel trellis frame, powder coated |
| Front SuspensionWP APEX 43 |
| HandlebarAluminium, tapered Ø 28/22 mm |
| Rear SuspensionWP APEX - Monoshock |
| SilencerStainless steel primary and secondary silencer |
| Steering Head Angle63.5° |
| Rear Subframe DesignSteel trellis frame, powder coated |
| Suspension Travel (Front)170 mm |
| Suspension Travel (Rear)177 mm |
| Trail98 mm |
| Weight (Without Fuel)161 kg |
| Wheelbase1430 mm |
| Seat Height855 mm |
| WheelsCast aluminium wheels |
| Front Wheel Diameter19 |
| Rear Wheel Diameter17 |
| Front Wheel Width2.5 |
| Rear Wheel Width3.5 |
