2024 KTM 790 DUKE
2024 KTM 790 DUKE
*Advertised 'Ride Away Price' including dealer fees, set-up and (if applicable) 12 months registration.
separator
THE SCALPEL
The KTM 790 DUKE has a reputation. Not only is it known to be devastatingly accurate, with the unmatched agility you'd expect from a single, merged with the meaty punch of a twin, but for being a no-nonsense street-brawler. Boasting an uncompromised 799 cc LC8c parallel twin motor nestled into one of the lightest and most compact chassis around, the KTM 790 DUKE is all about being fast where it counts - in the corners.
This motorcycle is designed and developed in Austria, and assembled in China.
MODEL
YEAR
TECHNICAL SPECIFICATION
| Drive TypeCombustion |
| Torque87 Nm |
| Transmission6-speed |
| Battery Capacity10 Ah |
| CoolingLiquid cooled |
| StarterElectric starter |
| Stroke65.7 mm |
| Bore88 mm |
| ClutchPASC™ antihopping clutch, mechanically operated |
| Displacement799 cm³ |
| EMSBosch EMS with RBW |
| Engine oilMotorex Power Synth SAE 10W-50 |
| Design2-cylinder, 4-stroke, parallel twin |
| Fuel-Mixture GenerationDKK Dellorto (Throttle body 46mm) |
| LubricationForced oil lubrication with 2 oil pumps |
| Tank Capacity (Approx.)14 l |
| ABSBosch 9.1 MP (incl. Cornering-ABS and super moto mode) |
| Front Brake Disc Diameter300 mm |
| Rear Brake Disc Diameter240 mm |
| Front Brake2x radially mounted 4 piston caliper |
| Rear BrakeSingle-piston floating calliper, brake disc |
| Chain520 X-Ring |
| Frame DesignChromium-Molybdenum-Steel frame using the engine as stressed element, powder coated |
| Front SuspensionWP APEX 43 |
| Rear SuspensionWP APEX - Monoshock |
| HandlebarAluminium Ø 28/22 mm |
| SilencerStainless steel primary and secondary silencer |
| Steering Head Angle66° |
| Rear Subframe DesignAluminium, powder-coated |
| Suspension Travel (Front)140 mm |
| Suspension Travel (Rear)150 mm |
| Trail98 mm |
| Weight (Without Fuel)174 kg |
| Wheelbase1475 mm |
| Wheelbase Tolerance15 mm |
| Ground Clearance186 mm |
| Seat Height825 mm |
| Front Wheel Diameter17" |
| Rear Wheel Diameter17" |
| Front Wheel Width3.5" |
| Rear Wheel Width5.5" |
