ADVENTURE EVERYWHERE
The KTM 890 ADVENTURE R proves that the destination comes second. With its unmatched ability to dispatch everything from highways to rocky gravel switchbacks, to single goat tracks, the KTM 890 ADVENTURE R boasts serious travel capabilities. Thanks to its incredibly responsive powerplant, pin-sharp offroad handling, and all-day comfort, its all about the journey.
MODEL
YEAR
TECHNICAL SPECIFICATION
| Transmission6-speed |
| StarterElectric starter |
| Stroke68.8 mm |
| Bore90.7 mm |
| Compression Ratio13.5 |
| Displacement889 cm³ |
| EMSBosch EMS with RBW |
| Design2-cylinder, 4-stroke, parallel twin |
| Fuel-Mixture GenerationDKK Dellorto (Throttle body 46mm) |
| Tank Capacity (Approx.)20 l |
| Front Brake Disc Diameter320 mm |
| Rear Brake Disc Diameter260 mm |
| Front Brake2x radially mounted 4 piston caliper |
| Rear Brake2 piston floating caliper |
| Chain520 X-Ring |
| Frame DesignChromium-Molybdenum-Steel frame using the engine as stressed element, powder coated |
| Front SuspensionWP XPLOR-USD, Ø 48 mm |
| HandlebarAluminium, tapered Ø 28/22 mm |
| Rear SuspensionWP XPLOR-Monoshock |
| Steering Head Angle63.7 ° |
| Rear Subframe DesignChromium-Molybdenum-Steel trellis, powder coated |
| Suspension Travel (Front)240 mm |
| Suspension Travel (Rear)240 mm |
| Weight (Without Fuel)200 kg |
| Wheelbase1528 mm |
| Ground Clearance263 mm |
| Seat Height880 mm |
| Wheels["2.50 x 21", "4.50 x 18"] |
| Tyre Dimensions (Front/Rear)90/90; 150/70 |
