LEADING THE CHARGE
The KTM SX-E 5 represents a new generation of advanced all-electric mini-cross that will entice and empower the next generation of KTM motorcyclist. Aimed at both beginner and competitive junior racers and with benchmark adjustable ergonomics - allowing the bike to 'grow' with the user - the KTM SX-E 5 is a high-quality and prime real-world READY TO RACE alternative to the petrol-powered 50 cc engine. The KTM SX-E 5 is not a toy: this is a bona fide platform for juniors that are finding all the joys of having a throttle in their right hand without the complications of emissions, complex maintenance, and noise. Whether riding, practicing or racing, the fresh KTM SX-E 5 is both everything they ever wanted and everything they'll ever need. This motorcycle is designed, developed, and produced in Austria.
TECHNICAL SPECIFICATION
| Rated output2 kW / 3,200 rpm |
| Torque13.8 Nm |
| Traction batteryLithium-Ion KTM PowerPack |
| Battery capacity21 Ah |
| Charger line voltage80-240 V/50-60 Hz |
| Charging inputQuick charging 5 A @ 230 V (AC) |
| Charging power900 W |
| Charging time 100 %70 min. |
| Charging time 80 %45 min. |
| CoolingLiquid cooled |
| Energy content0.907 kWh |
| Electric motor48 V - BLDC motor with outer rotor |
| Max. motor speed6000 rpm |
| Max. power5 kW / 3,900 rpm |
| Front Brake Disc Diameter160 mm |
| Rear Brake Disc Diameter160 mm |
| Front BrakeDisc brake |
| Rear BrakeDisc brake |
| Chain415, Non-sealed |
| Frame DesignChrome-molybdenum steel central-tube frame |
| Front SuspensionXACT 35 WP Upside-Down fork, Ø 35 mm |
| HandlebarTapered aluminum Ø 28/22/18 mm |
| Rear SuspensionXACT WP mono shock |
| Steering Head Angle66° |
| Rear Subframe DesignGlass fiber reinforced plastic |
| Suspension Travel (Front)205 mm |
| Suspension Travel (Rear)193 mm |
| Weight40.5 kg |
| Wheelbase1028 mm |
| Ground Clearance259 mm |
| Seat Height682 mm |
