2027 KTM 690 RALLY
2027 KTM 690 RALLY
*Advertised 'Ride Away Price' including dealer fees, set-up and (if applicable) 12 months registration.
separator
Inquiring for 2027 KTM 690 RALLY
Fill out the form below and one of our friendly sales team will be in touch.
GO OUT. MEET YOURSELF.
The KTM 690 RALLY is built for riders who go beyond the familiar. Designed for long-distance off-road travel and Rally Raid-inspired performance, it delivers the range, control, and capability to push deeper into the unknown.
MODEL
YEAR
TECHNICAL SPECIFICATION
| Design1-cylinder, 4-stroke engine |
| Engine CylinderSingle cylinder |
| Engine Stroke4-Stroke |
| Displacement692.7 cm³ |
| Power79 PS |
| Torque73 Nm |
| Transmission6-speed |
| CO2 Emissions99 g/km |
| CoolingLiquid cooled |
| EMSKeihin EMS with RBW, twin ignition |
| Engine OilMotorex Power Synth SAE 10W-50 |
| SilencerStainless steel primary and secondary silencer |
| Frame DesignChromium-Molybdenum steel trellis frame, powder coated |
| Front BrakeBrembo twin-piston floating calliper, brake disc |
| Rear BrakeBrembo single-piston floating calliper, brake disc |
| Front Brake Disc Diameter300 mm |
| Rear Brake Disc Diameter240 mm |
| Brake Disc Diameters (Front/Rear)300 / 240 mm |
| Chain520 X-Ring |
| Steering Head Angle62.3 ° |
| Rear Subframe DesignSelf-supporting plastic tank |
| Trail121 mm |
| Wheelbase1506 mm |
| Seat Height935 mm |
| Wheelbase1506 ± 15 mm |
| Wheelbase Tolerance0.59 inch |
| Tank Capacity (Approx.)20 l |
| Ground Clearance265 mm |
| Weight (Without Fuel)161.5 kg |
| WheelsSpoked wheels with aluminium rims |
| Wheel Sizes1.85 x 21"; 2.5 x 18" |
