GO FURTHER. PLAY HARDER.
Lightweight Agility. The tougher the ride, the better it gets.
Standard Equipment:
- Enduro-tune KYB suspension
- Brembo Brakes
- DID and Michelin Tyres
- Lightweight Aluminium Spine Frame
- Dual Engine Maps (Athena)
- Cutting-edge technology including traction control, launch control, quickshifter
MODEL
YEAR
TECHNICAL SPECIFICATION
Type1-cylinder, 4-stroke SOHC |
Capacity249.9 cc |
Bore78 mm |
Stroke52.3 mm |
Compression14.4 |
Max Power EC42.3 PS |
Max Torque EC27.8 Nm |
SystemDellorto 44mm Cable Throttle, EFI |
ExhaustSingle Silencer |
Final Drive13/52 |
ClutchAluminium separate basket Wet; Multiple Disc Hydraulic |
Gearbox6 speed |
FrameAluminium, Spine |
SwingarmAluminium Fabrication |
Front SuspensionKYB 48mm Coil Spring Fork, Compression/Rebound Adjustment, 300mm Travel |
Rear SuspensionKYB Coil, Compression Adjustment (High and Low Speed), Rebound Adjustment, 313mm Travel |
Front BrakesSingle, Ø260 Galfer Disc, Brembo, 2xØ24 pistons, floating caliper |
Rear BrakesSingle, Ø220 Galfer Disc, Brembo, 1xØ26 pistons, floating caliper |
Instrument Display and FunctionsSpeedo, Multi-Function Switch Cubes |
Traction Control |
Launch Control |
Quick Shifter |
Dual Engine Maps |
D.I.D. DirtStar Aluminium Wheels |
Michelin Enduro 2 Tyres |
Pyramid Non-slip Seat Cover |
Galfer Discs |
Neken Triple Clamps |
Pro Taper Bars |
ODI Grips |
Width Handlebars836 mm |
Height Without Mirror1264 mm |
Seat Height955 mm |
Wheelbase1488 mm [1497 mm]* |
Rake26.8° |
Trail113 mm |
Tank Capacity8.3 L |
Wet Weight114.2 kg |
Front Wheel21” x 1.6” |
Rear Wheel18” x 2.15” |
Front Tyre90/90 – 21 |
Rear Tyre140/90 – 18 |
