Regulator Rectifier - Suzuki AN400 \'09-\'16 (RMS020-107259)

Regulator Rectifier - Suzuki AN400 \'09-\'16 (RMS020-107259)

$269.99
$269.99

In Store

Available now for delivery or store pickup, during store hours.

Warehouse

Available for delivery or store pickup during store hours in 2-5 business days time.

Contact us for availability

We are currently out of stock for this product.
Or split over 4 payments with Afterpay Afterpay
SHARE:
View full details

Brand new aftermarket Voltage Regulator Rectifier

  • Direct replacement to your original unit
  • Plug-and-play, direct fit, easy installation
  • No assembly required
  • Higher-grade of electric components
  • The quality exceeds the OEM equipment
  • All products shipped are tested

Specifications:

Dimensions:

  • Width: 80 mm
  • Length: 110 mm
  • Height: 28 mm
  • Wires length: 130 mm
  • Distance between fixation holes center to center: 74 mm

    • Other specifications:

    • Number of plugs: 2
    • Number of pins: 7
    • Number of wires: 7
    • Minimum Charging Voltage: 14.5 V +- 0.5 V
    • Maximum Charging Current: 50 A / 500 W
    • Open Circuit Voltage: < 15 V
    • Operation Temperature: -20°C to 85°C

    *The product images shown are for illustration purposes only and may not be an exact representations of the product. Cullys Yamaha reserve the right to change product images and specifications at anytime without notice. Additional products may be displayed within image to illustrate the product offered for sale
