SCRAMBLER 400 X
SCRAMBLER 400 X
*Advertised 'Ride Away Price' including dealer fees, set-up and (if applicable) 12 months registration.
separator
Beautifully balanced, effortlessly agile. The Scrambler 400 X is built for all riders, and all terrains. Hit those hot summer savings today.
MODEL
YEAR
TECHNICAL SPECIFICATION
| TypeLiquid-cooled, 4 valve, DOHC, single-cylinder |
| Capacity398.15 cc |
| Bore89.0 mm |
| Stroke64.0 mm |
| Compression12:1 |
| Max Power EC40 PS / 39.5 bhp (29.4 kW) @ 8,000 rpm |
| Max Torque EC37.5 Nm @ 6,500 rpm |
| SystemBosch electronic fuel injection with electronic throttle control |
| ExhaustStainless twin-skin header system with stainless steel silencer |
| Final DriveX-ring chain |
| ClutchWet, multi-plate, slip |
| Gearbox6 speed |
| FrameHybrid spine/perimeter, tubular steel, bolt-on rear subframe |
| SwingarmTwin-sided, cast aluminium alloy |
| Front WheelCast aluminium alloy 10 spoke, 19 x 2.5 in |
| Rear WheelCast aluminium alloy 10 spoke, 17 x 3.5 in |
| Front Tyre100/90-19 |
| Rear Tyre140/80-17 |
| Front Suspension43mm upside down Big Piston forks. 150mm wheel travel |
| Rear SuspensionGas monoshock RSU with external reservoir and pre-load adjustment. 150mm wheel travel |
| Front Brakes320mm fixed disc, four-piston radial caliper, ABS |
| Rear Brakes230mm fixed disc, ByBreTM single piston floating caliper, ABS |
| Instrument Display and FunctionsAnalogue speedometer with integrated multi-function LCD screen |
| CO2 Figures83.8 g/km EURO 5 CO2 emissions and fuel consumption data are measured according to regulation 168/2013/EC. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving results. |
| Width Handlebars901 mm |
| Height Without Mirror1169 mm |
| Seat Height835 mm |
| Wheelbase1418 mm |
| Rake23.2 º |
| Trail108 mm |
| Tank Capacity13 L |
| Wet Weight179 kg |
