SCRAMBLER 400 XC
SCRAMBLER 400 XC
*Advertised 'Ride Away Price' including dealer fees, set-up and (if applicable) 12 months registration.
separator
Inquiring for SCRAMBLER 400 XC
Fill out the form below and one of our friendly sales team will be in touch.
Experience rugged Triumph Scrambler attitude and ability.
The new Scrambler 400 XC is built strong, from its beautifully-crafted spoked wheels and tubeless tyres to tough protection features and purposeful high-level front mudguard. Embrace the thrill and discover the freedom to venture off the beaten track.
MODEL
YEAR
TECHNICAL SPECIFICATION
| TypeLiquid-cooled, 4 valve, DOHC, single-cylinder |
| Capacity398.15 cc |
| Bore89.0 mm |
| Stroke64.0 mm |
| Compression12:1 |
| Max Power EC40 PS / 39.5 bhp (29.4 kW) @ 8,000 rpm |
| Max Torque EC37.5 Nm @ 6,500 rpm |
| SystemBosch electronic fuel injection with electronic throttle control |
| ExhaustStainless twin-skin header system with stainless steel silencer |
| Final DriveX-ring chain |
| ClutchWet, multi-plate, slip |
| Gearbox6 speed |
| FrameHybrid spine/perimeter, tubular steel, bolt-on rear subframe |
| SwingarmTwin-sided, cast aluminium alloy |
| Front WheelSpoked Tubeless, 19 x 2.5 in |
| Rear WheelSpoked Tubeless, 17 x 3.5 in |
| Front Tyre100/90-19 |
| Rear Tyre140/80-17 |
| Front Suspension43mm upside down Big Piston forks. 150mm wheel travel |
| Rear SuspensionGas monoshock RSU with external reservoir and pre-load adjustment. 150mm wheel travel |
| Front Brakes320mm fixed disc, four-piston radial caliper, ABS |
| Rear Brakes230mm fixed disc, ByBreTM single piston floating caliper, ABS |
| Instrument Display and FunctionsAnalogue speedometer with integrated multi-function LCD screen |
| CO2 Figures83.8 g/km EURO 5 CO2 emissions and fuel consumption data are measured according to regulation 168/2013/EC. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving results. |
| Height Without Mirror1169 mm |
| Seat Height835 mm |
| Wheelbase1418 mm |
| Rake23.2 º |
| Trail108 mm |
| Tank Capacity13 L |
| Wet Weight186 kg |
